E R Water stop collet Tooling System

Water stop collet

Contact now

FEATURE
INQUIRY

ER11C		ER16C		ER20C
MODEL	CLAMP RANGE	MODEL	CLAMP RANGE	MODEL	CLAMP RANGE
ER11-3C	3-2.9	ER16-3C	3-2.9	ER20-3C	3-2.9
ER11-4C	4-3.9	ER16-4C	4-3.9	ER20-4C	4-3.9
ER11-4.5C	4. 5-4. 4	ER16-4. 5C	4. 5-4.4	ER20-5C	5-4.9
ER11-5C	5-4.9	ER16-5C	5-4.9	ER20-5. 5C	5. 5-5.4
ER11-5.5C	5. 5-5. 4	ER16-5. 5C	5. 5-5.4	ER20-6C	6-5.5
ER11-6C	6-5.9	ER16-6C	6-5.5	ER20-6. 5C	6. 5-6
ER11-6.5C	6. 5-6.4	ER16-6. 5C	6. 5-6	ER20-7C	7-6.5
ER11-7C	7-6.9	ER16-7C	7-6.5	ER20-7. 5C	7. 5-7
		ER16-7. 5C	7.5-7	ER20-8C	8-7.5
		ER16-8C	8-7.5	ER20-8. 5C	8. 5-8
		ER16-8. 5C	8. 5-8	ER20-9C	9-8.5
		ER16-9C	9-8.5	ER20-9. 5C	9. 5-9
		ER16-9. 5C	9. 5-9	ER20-10C	10-9. 5
		ER16-10C	10-9.5	ER20-10. 5C	10. 5-10
				ER20-11C	11-10.5
				ER20-11.5C	11.5-11
				ER20-12C	12-11.5
				ER20-12. 5C	12. 5-12
				ER20-13C	13-12.5
ER25-3C	3-2.9	ER32-3C	3-2.9	ER40-4C	4-3.9
ER25-4C	4-3.9	ER32-4C	4-3.9	ER40-5C	5-4.9
ER25-5C	5-4.9	ER32-5C	5-4.9	ER40-6C	6-5.9
ER25-6C	6-5.5	ER32-6C	6-5.9	ER40-7C	7-6.9
ER25-6. 5C	6. 5-6	ER32-7C	7-6.9	ER40-8C	8-7.9
ER25-7C	7-6.5	ER32-8C	8-7.5	ER40-9C	9-8.9
ER25-7. 5C	7. 5-7	ER32-8. 5C	8. 5-8	ER40-10C	10-9. 5
ER25-8C	8-7.5	ER32-9C	9-8.5	ER40-10. 5C	10. 5-10
ER25-8. 5C	8. 5-8	ER32-9. 5C	9. 5-9	ER40-11C	11-10.5
ER25-9C	9-8.5	ER32-10C	10-9.5	ER40-11.5C	11.5-11
ER25-9. 5C	9. 5-9	ER32-10.5C	10.5-10	ER40-12C	12-11.5
ER25-10C	10-9. 5	ER32-11C	11-10.5	ER40-12. 5C	12. 5-12
ER25-10. 5C	10. 5-10	ER32-11.5C	11.5-11	ER40-13C	13-12. 5
ER25-11C	11-10.5	ER32-12C	12-11.5	ER40-13. 5C	13. 5-13
ER25-11.5C	11.5-11	ER32-12. 5C	12.5-12	ER40-14C	14-13. 5
ER25-12C	12-11.5	ER32-13C	13-12.5	ER40-14. 5C	14. 5-14
ER25-12. 5C	12. 5-12	ER32-13. 5C	13.5-13	ER40-15C	15-14.5
ER25-13C	13-12.5	ER32-14C	14-13.5	ER40-15. 5C	15. 5-15
ER25-13.5C	13. 5-13	ER32-14. 5C	14.5-14	ER40-16C	16-15. 5
ER25-14C	14-13.5	ER32-15C	15-14.5	ER40-16. 5C	16. 5-16
ER25-14. 5C	14.5-14	ER32-15. 5C	15.5-15	ER40-17C	17-16.5
ER25-15C	15-14.5	ER32-16C	16-15.5	ER40-17. 5C	17. 5-17
ER25-15.5C	15. 5-15	ER32-16. 5C	16. 5-16	ER40-18C	18-17.5
ER25-16C	16-15.5	ER32-17C	17-16.5	ER40-18. 5C	18. 5-18
		ER32-17. 5C	17.5-17	ER40-19C	19-18. 5
		ER32-18C	18-17.5	ER40-19. 5C	19. 5-19
		ER32-18.5C	18.5-18	ER40-20C	20-19. 5
		ER32-19C	19-18.5	ER40-20. 5C	20. 5-20
		ER32-19.5C	19.5-19	ER40-21C	21-20. 5
		ER32-20C	20-19. 5	ER40-21. 5C	21. 5-21
				ER40-22C	22-21. 5
				ER40-22.5C	22. 5-22
				ER40-23C	23-22. 5
				ER40-23.5C	23. 5-23
				ER40-24C	24-23. 5
				ER40-24.5C	24. 5-24
				ER40-25C	25-24. 5
				ER40-25.5C	25. 5-25
				ER40-26C	26-25. 5
